An Optical Shaft Measuring System that achieves high-speed and high-accuracy measurements and can be automated on the shop floor. The size tolerance and geometric tolerance of a shaft-shaped workpiece can be evaluated quickly.
Outstanding Features:
-       Line scan camera (7,500 pixels) sensor enables high-speed measurement that realizes high accuracy and high resolution
-       The tactile probe can accurately measure the shape of keyways, holes, and other shaded objects that an optical sensor cannot measure, as well as the run-out in the axial direction (for Shaftcom C with T3D only)
-       Accuracy with optical sensor (MPE): Diameter (1.0 + D/200) μmLength   (2.6 + L/200) μm
-       Accuracy with tactile probe (MPE) Diameter (3.7 + D/200) μm Length     (3.6 + L/200) μm
-       Camera with IP52 protection against liquids and dust. Sealing cover protects the headstock and built-in master from oil, dust, and dirt.
-       Tolaris Optic, measurement and analysis software, is easy for anyone to operate.
-       Characteristics: size tolerance, geometric tolerance, and screw shape can be evaluated in a single measurement.
-       Automatic correction of the environmental temperature before the measurement program runs.
